User interface BODAC - General 4
Title bar
The title bar contains the name of the program/window and several standard Windows
buttons. Information about the standard Windows buttons can be found in your
Windows online help.
Menu bar
The menu bar lists all the menus and commands available in BODAC.
The following menus are available:
n File menu
n Controller menu
n View menu
n Configuration menu
n Options menu
n Application Window menu
n Windows menu
n Help menu
BODAC toolbar
The toolbar contains buttons with symbols (icons) execute the most commonly used
functions, invoke commands or open windows when clicked on with the mouse.
Following is a list of the available functions:
Generates the “Offline” command, which breaks the connection to the
controller card. The symbol is only visible if there is an active connection to
the card.
Generates the “Connect” command. The symbol is only visible if there is no
active connection to the card.
Opens the “Open” window, where you can select stored BODAC data files.
Opens the “Save file as” window, in which you can save your entries.
Opens the "Analog in-/outputs“ (“Analog I/O”) window.
Opens the "Status“ window.
