REXROTH VT-VRPD-2 - Status Bar; Short Cut List

RE 30126-01-B/08.07 | Manual Hydraulics | Bosch Rexroth AG 38/76
User interface BODAC - General 4
If you are in an entry field, you can click on the symbol “+” to increment
the field contents. Simultaneously BODAC writes this parameter to the
card.
Exception: Multiplot, see “Multiplot toolbar”
If you are
in an entry field, you can click on the "
-
" symbol to
decrement the field contents. Simultaneously BODAC writes this
parameter to the card.
Exception: Multiplot, see “Multiplot toolbar”
The Undo symbol in the toolbar nullifies the last entry.
Clicking on the oscilloscope symbol in the toolbar opens the BODAC
window “Multiplot”.
To show signals in the Multiplot window, open the Motion Data window
and click on the name of the desired signal. The name of the signal is
highlighted in red to indicate that it is selected for display in the
Multiplot window. Then click on the oscilloscope symbol in the toolbar
to open the Multiplot window. The signals you selected will be
displayed.
You can also select more signals once the "Multiplot" window is
opened.
A maximum of 8 signals can be selected.
Clicking on the printer symbol in the toolbar opens the Windows
system window “Print”.
The Help symbol in the toolbar generates a help pointer. Clicking with
the help pointer on a parameter field opens the help for this parameter
field.
The Data Log symbol in the toolbar generates a file with the extension
“.log” in which all motion data are stored.
Status bar
The status bar contains useful information about the active window. For example the
main menu shows the current connection status.
Short cut list
You can also invoke important functions using the function keys on the keyboard. The
function keys are defined as follows:
F1
Opens BODAC Help (see also “Help menu”)
F2
Reads the currently saved data in the co
ntroller card and sends them
to the BODAC program. (see also “Read Parameters”)
