RE 30126-01-B/08.07 | Manual Hydraulics | Bosch Rexroth AG 8/76
Overview of the 4WRE 6 and 4WRE 10 – Valve control 2
2.2 Electrical and hydraulic installation plan
Fig. 1 Block schematic of VT -VRPD card
