3.2 INSTALLATION PROCEDURE
1. Remove the tape strips and the cushions [A] as shown.
2. While raising the lock plate [B], slide the platen cover [C] to the right and
remove it.
3. Remove the platen cover mounting screws [D].
[A]
[A]
[B]
[C]
[D]
[D]
A172/A199 3-34 SM
