ITEM EM 40K 80K 120K 160K 200K NOTE
Hot Roller Ball Bearing
CCCRC
Clean with dry cloth.
(
NOTE 4
)
Pressure Roller*
,
Pressure Roller Ball
Bearing
R
Barrierta L55/2 (
NOTE 5
)
Oil Blade
CRCRC
Suitable solvent
Apply silicone oil on the
edge after cleaning or
replacement.
Oil Supply Pad
RRRRR
Oil Sump
C
Dry cloth and alcohol
Hot Roller Stripper
CCCCC
Suitable solvent
Apply silicone oil on the
top after cleaning.
Fusing Thermistor,
Pressure Roller Thermistor
CCCCC
Suitable solvent
Apply silicone oil on the
surface after cleaning.
Oil Tank
I C/L I C/L C/L
Add silicone oil after
removing paper dust with
a pipette.
Fusing Drive Gears
LL
Mobil Temp. 1 or 78
(
NOTE 4
)
Cleaning Roller,
Cleaning Roller Scraper
CCCCC
Suitable solvent
Pressure Roller
Cleaning Roller
CCCCC
Suitable solvent
OTHERS
Transport Belts
CCCCC
Alcohol
Toner Collection Bottle
ICCCCC
Clean at EM if necessary.
Inner Cooling Fan Filter
RRRRR
(
NOTE 1
)
OPTIONAL EQUIPMENT
SORTER (A511) (Number of Copies)
Transfer Rollers
CCC C C C
Alcohol
Exit Rollers
CCC C C C
Alcohol
Gears and Bushings
(L) (L) (L) (L) (L) (L)
Lubricate if noisy.
DUAL JOB FEEDER (A376) (Number of Originals)
ITEM EM 48K 96K 144K 192K 240K NOTE
Transport Belt
CRR R R R
Belt cleaner
Replace if necessary.
Pick-up Roller
CCC C C C
Alcohol
Replace if necessary.
Feed Roller
CRR R R R
Alcohol
Replace if necessary.
A172/A199 4-72 SM
To Next Page
