Tech Service Bulletin No. A172/A199 – 016
Page 7 of 17
•
Development Check Points
1.
Magenta Banding –
Install the Ball Bearing 6x10x3 (08053496) as shown, on the magenta sleeve roller
bias pin.
2.
Poor copy quality -
Apply conductive grease KS660 SHIN-ETSU (G0049668) to the sleeve Roller bias
pins. Do not apply the conductive grease into the HV receptacles.
3.
When vacuuming the Development Units –
Hold the development unit casing to avoid damaging the
TD sensors. Do this or remove the sensors.
4.
To avoid damaging the TD sensors -
Ensure that all filters are replaced at the recommended PM
interval. Clogged filters cause the temperature to increase around the TD sensors and can result in
erratic TD sensor operation.
Continued…
