Bit Switches - 4
SM 119 D418
Fax Option
Type 9001
D418
G3 Switch 07 (SP No. 1-105-008)
No Function Comments
0: Disabled
1: Enabled
5 Not used Do not change the settings.
6
Parameter selection for the dial tone
detection
0: Normal parameter
1: Specific parameter
0: This uses a fixed table in ROM for the
dial tone detection.
1: This uses a SRAM value that can be
adjusted for the dial tone detection.
Select this if the dial tone cannot be
detected when "Normal parameter: 0" is
selected.
7 Not used Do not change the settings.
G3 Switch 08 - Not used (do not change the settings)
G3 Switch 09 - Not used (do not change the settings)
G3 Switch 0A (SP No. 1-105-011)
No Function Comments
Maximum allowable carrier drop
during image data reception
Bit 1 Bit 0 Value (ms)
0 0 200
0 1 400
0-1
1 0 800
These bits set the acceptable modem
carrier drop time.
Try a longer setting if error code 0-22 is
frequent.
To Next Page
