Electrical Components
SM 123 D454
Multi-Folding
Unit FD5000
D454
2.5.9 SENSORS AROUND TOP TRAY
1. Top Tray Full Sensor (R)
2. Entrance JG HP Sensor
3. Top Tray Full Sensor (E)
4. Top Tray Exit Sensor
5. Top Tray Paper Path Sensor
6. Entrance Sensor
7. Horizontal Path Paper Sensor
8. Vertical Path Paper Sensor
9. Horizontal Path Exit Sensor
