Details
D454 128 SM
Motors
M
Dynamic Roller Transport
Motor
Drives the Dynamic roller.
M
Registration Roller Transport
Motor
Drives the registration roller.
M Direct-Send JG Motor
Operates the direct send junction gate to the
Stopper 2.
M FM6 Pawl Motor
Drives the double-flap pawl that prevents
bending of the leading edge when the 3rd fold
is executed for FM6 folding (Fourths with 2
Flaps In)
M Stopper 3 Motor
Moves Stopper 3 to the correct position for
folding according to the paper size.
M 2nd Fold Motor
Drives 3rd fold roller. Reverses when the
paper does not pass through the 3rd fold unit.
M Crease Motor Drives the crease rollers.
Sensors
S Top Tray Exit Sensor
Checks for the presence of paper at power
on. Detects paper jams at the exit of the
top tray. Used to create timing for control
of paper fed to the top tray.
S Entrance Sensor
Checks for the presence of paper at power
on. Detects paper jams of paper fed from
the upstream unit. Used to create timing
for operation of the shift roller during
multiple-sheet folding.
S Entrance JG HP Sensor
Detects when the entrance junction gate is
in and out of its home position.
