Electrical Components
SM 127 D454
Multi-Folding
Unit FD5000
D454
Motors
M Top Tray Transport Motor
Drives the transport rollers that feed unfolded
paper to the downstream unit. Reverses and
feeds folded paper to the folded paper tray.
M Horizontal Transport Motor
Drives the entrance roller at the entrance
where the paper from the upstream device is
received. Drives the exit roller that feeds the
paper out to the downstream unit. Drives
other transport rollers in the horizontal paper
path.
M Top Tray Exit Motor
Drives the exit roller that feeds paper into the
top tray.
M 1st Fold Motor Drives the 1st fold roller.
M Jogger Fence Motor
Moves the jogger fence according to the
width of the paper to align its edges.
M Positioning Roller Motor
Operates the positioning roller when the
paper strikes stopper 1 when more that one
sheet of paper is stacked for folding.
M Stopper 1 Motor
Moves Stopper 1 to the correct position for
folding according to the paper size.
M Fold Plate Motor
Operates the fold plate for the first fold during
multi-sheet folding. Operates Stopper 1 1
during Z-folding.
M
Registration Roller Release
Motor
Releases the pressure of the registration
roller so paper can be stacked for multi-sheet
folding.
M Dynamic Roller Lift Motor
Raises and lowers the dynamic roller to the
correct position for folding.
M Stopper 2 Motor
Moves Stopper 2 to the correct position for
folding according to the paper size.
