D454 126 SM
2.5.11 BOARDS, SWITCHES, FAN
1. Main Board
2. Front Door Switch
3. PSU
4. PSU Fan
5. Breaker Switch
2.5.12 COMPONENT LIST
Motors
M Entrance JG Motor
Operates the entrance junction that directs
paper from the upstream device to the 1)
horizontal paper path, 2) paper fold path, 3)
top tray.
