Service Call Conditions
SM Appendix 3-3 D062/D063/D065/D066
Appendix:
Service Call
Conditions
DF glass dirty or has condensation
Scanner mirror dirty, out of position or has condensation
Lens dirty, out of position
Scanner home position error 1
D
The scanner HP sensor does not detect the OFF condition during
initialization or copying.
120
-
BCU, SIOB defective
Scanner motor defective
Scanner HP sensor defective.
Harness between BCU, SIOB, scanner motor disconnected.
Harness between scanner HP sensor and BCU disconnected.
Scanner wire, timing belt, pulley, or carriage installed incorrectly.
Scanner home position error 2
D
The scanner HP sensor does not detect the ON condition during initialization
or copying.
121
-
BCU, SIOB defective
Scanner motor defective
Scanner HP sensor defective
Harness between BCU, SIOB, scanner motor disconnected
Harness between scanner HP sensor and BCU disconnected
Scanner wire, timing belt, pulley or carriage installed incorrectly.
Black level detection error
The black level cannot be adjusted within the target during auto gain control.
141 D
Harness between SBU – SIOB is disconnected.
Harness between SIOB – BCU is disconnected.
Defective SBU
Defective BCU
