Service Call Conditions
D062/D063/D065/D066 3-56 SM Appendix
Self-diagnostic error: HDD
3003
Check performed when
HDD is installed:
HDD device busy for
over 31 s.
After a diagnostic
command is set for
Sthe HDD, but the
device remains busy
for over 6 s.
A diagnostic command is
issued to the HDD device
but the result is an error
HDD defective
HDD harness disconnected,
defective
Controller board defective
3004
No response to the
self-diagnostic command
from the ASIC to the HDDs
HDD defective
3013
Mandolin does not respond,
the HDD device remains
BUSY for more than 31 s,
or the BUSY signal does
not drop within 6 s after the
diagnostic command is
issued to the HDDs.
HDD defective
HDD connector loose or defective
Controller defective
822 B
3014
Error returned from HDD in
response to the
self-diagnostic command,
Mandolin could not be
located due to a read/write
error at the HDD register.
HDD defective
To Next Page
