Removing Paper Jams
Pull the opening lever on the front cover, and then carefully lower
the front cover.
Pull out the jammed paper carefully.
If paper has become jammed inside the
transfer unit, pull the paper forward.
• Do not pull out the paper tray (Tray 1).
• If paper is jammed in tray 2 but is difficult to locate, pull out
tray 2 to remove it. After removing the paper, carefully
push tray 2 all the way back inside the machine.
Using both hands, carefully push up the front cover until it
closes.
• When closing the front cover, push the upper area of the cover firmly. After closing the cover,
check that the error is cleared.
BAA309S
BAA310S
Removing from the Tray
