2. Touch Panel
Displays the Home screen, operation screen of applications, and messages. Operate with the fingertips.
page 27 "How to Use the Home Screen"
page 29 "Intuitive Screen Operation Using Fingertips"
3. NFC tag
Used to connect the machine and a smart device with the RICOH Smart Device Connector.
See "Using the Machine Functions from a Mobile Device", User Guide (Full Version).
• You can adjust the angle of the control panel to improve visibility.
LED Indicators
Names and Functions of the Control Panel
21
