IM 350F IM 430Fb/IM 430F
Maximum 1380 W 1390 W
The power level when the main switch is turned off and the power cord is plugged into
an outlet: 1 W or less
• Complete system
IM 350F IM 430Fb/IM 430F
Maximum 1380 W or less 1390 W or less
The complete system consists of the main unit, ADF, lower paper trays (three unit), Copy
Data Security unit, HDD, fax unit, memory unit.
Dimensions:
• W × D × H up to ADF:
476 × 442 × 510 mm (18.7 × 17.4 × 20.0 inches)
Space for main unit (W × D):
511 × 617 mm (20.1 × 24.3 inches) (including the bypass tray and output tray)
Noise emission
• Sound power level:
• Main unit only
IM 350F/IM 350 IM 430Fb/IM 430F
Stand-by 30.6 dB (A) 29.6 dB (A)
Copying 60.1 dB (A) 62.0 dB (A)
• Complete system
IM 350F/IM 350 IM 430Fb/IM 430F
Stand-by 30.2 dB (A) 30.0 dB (A)
Copying 66.6 dB (A) 65.9 dB (A)
• Sound pressure level:
• Main unit only
Specifications for the Main Unit
283
