When moving the machine, do not hold on the following parts as doing so could cause a
malfunction:
The handle onto the standard paper feed tray
The underside of the bypass tray
5. There are three upright pins on the optional paper feed unit. Align them with the holes on
the underside of the machine, and then carefully lower the machine.
DVL103
6. Plug in the power cord, and then turn on the machine.
7. Print the configuration page to confirm that the unit was attached correctly.
The number of tray that you can install
Person who install
Use on table: printer and one or two optional
paper feed units
Use on table: printer
and three optional
paper feed units
*1
Attaching the Paper Feed Unit
41
