Page #152 background imageLoading...
Page #152 background image
8. In the [Groups or user names:] list, select a group or user, and then, in the [Allow] column
of the permissions list, select either the [Full Control] or [Modify] check box.
9. Click [OK].
Registering an SMB Folder
If User Authentication is specified, contact your administrator.
1. Press [Home] ( ) at the bottom of the screen in the center.
2. Flick the screen to the left, and then press the [Address Book Management] icon.
3. Check that [Program / Change] is selected.
4. Press [New Program].
5. Press [Change] under "Name".
The name entry display appears.
6. Enter the name, and then press [OK].
7. Press [ Next].
8. Press the key for the classification you want to use under "Select Title".
The keys you can select are as follows:
• [Frequent]: Added to the page that is displayed first.
• [AB], [CD], [EF], [GH], [IJK], [LMN], [OPQ], [RST], [UVW], [XYZ], [1] to [10]: Added to the
list of items in the selected title.
You can select [Frequent] and one more key for each title.
5. Scan
150

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh IM430 Series and is the answer not in the manual?

Ricoh IM430 Series Specifications

General IconGeneral
Copy Resolution600 x 600 dpi
Duplex PrintingYes
Print Speed (Black)43 ppm
Print Resolution1200 x 1200 dpi
Copy Speed (Black)43 cpm
Scan Resolution600 dpi
ConnectivityEthernet
Weight26 kg
Network ConnectivityEthernet (10Base-T/100Base-TX/1000Base-T)
Operating System CompatibilitymacOS
