2. Remove the protective tape from the handset bracket.
DVL391
3. Attach the bracket to the left side of the machine, as shown below.
DVL392
1
2
4. Remove the inquiry card from the handset cradle.
The card can be easily removed by pushing it from the back of the handset.
DVL393
1
2
Installing the Handset
(mainly North America)
