SERVICE PROGRAM MODE 1 March, 2000
4-42
4. Input Test Mode
SP No. Display
4-020 Scanner HP Sensor
4-021-1 Original Length SN 0
4-021-2 Original Length SN 1
4-021-3 Original Width SN 2
4-021-4 Original Width SN 3
4-021-5 Original Length SN 4
4-021-6 Original Length SN 5
4-022 Platen Cover Sensor
4-040 Master Unit Set Sensor
4-041 Cutter HP Sensor
4-042 Master Set Sensor
4-043 Master End Sensor
4-044 Master Edge Sensor
4-046 Platen Release Sensor
4-060 Eject Box Set Sensor
4-061 Paper Eject Sensor
4-062 Pressure Plate HP Sensor
4-063 Pressure Plate Limit SN
4-080 Paper Table Lowering SW
4-081 Paper End Sensor
4-082 Table Lower Limit Sensor
4-083 Paper Table Height SN
4-084 Paper Registration SN
4-085 Paper Feed Timing Sensor
4-086-1 Paper Feed Pressure 0
4-086-2 Paper Feed Pressure 1
4-086-3 Paper Feed Pressure 2
4-086-4 Paper Feed Pressure 3
4-087-1 Separation Pressure 0
4-087-2 Separation Pressure 1
4-087-3 Separation Pressure 2
4-087-4 Separation Pressure 3
4-088 Paper Table Set Sensor
4-089 Paper Feed Start Sensor
4-090-1 Paper Width Detection 0
4-090-2 Paper Width Detection 1
4-090-3 Paper Width Detection 2
4-090-4 Paper Width Detection 3
4-090-5 Paper Width Detection 4
4-090-6 Paper Width Detection 5
4-091 Paper Length Sensor
4-092 Relay Guide Set Sensor
4-100 Paper Exit Sensor
