Ricoh JP5800 - Page 110

1 March, 2000 SERVICE PROGRAM MODE
4-43
Service
Tables
SP No. Display
4-101-1
Wing Upper Position SN
4-101-2
Wing Lower Position SN
4-120-1
1st Drum Position Sensor
4-120-2
2nd Drum Position Sensor
4-120-3
Drum Home Position Sensor
4-122-1
Drum Type Check 0
4-122-2
Drum Type Check 1
4-123
Ink Pump Sensor
4-124
Ink Cartridge Set Sensor
4-125
Ink Detection
4-126
Drum Idling Roller HP SN
4-127-1
1st Drum Master Sensor
4-127-2
2nd Drum Master Sensor
4-128
Lower Wrapping Jam SN
4-129-1
A3 Cam Sensor
4-129-2
A4 Cam Sensor
4-131
Main Motor Lock Detect
4-140 Image Shift HP Sensor
4-141 Drum Shift HP Sensor
4-142-1 Clamp Close Position SN
4-142-2 Clamper Open Position SN
4-143 P Cylinder Feed Encoder
4-144 Tray Feed Start Sensor
4-400 Front Door Open Detect
4-500 DF Installation Detect
4-501 DF Cover Open Sensor
4-502 DF Registration Sensor
4-503 DF Original Set Sensor
4-504-1 DF Original Width SN 1
4-504-2 DF Original Width SN 2
4-504-3 DF Original Width SN 3
4-504-4 DF Original Length SN 1
4-504-5 DF Original Length SN 2
4-505 DF Position Sensor
4-506 DF APS Start Sensor
4-520 Slider Upper Limit SN
4-521 Job Separator Paper SN
4-522 Slider Position Sensor
4-523 Slider HP Sensor
4-540-1 PDTable Paper End (Delivery table paper sensor)
4-540-2 PDTable S-Plate Position (Side plate set sensor)
4-540-3 PDTable S-Plate Pulse SN
4-540-4 PDTable S-Plate HP SN
4-540-5 PDTable E-Plate Position (End plate set sensor)
4-540-6 PDTable E-Plate Pulse SN
