SERVICE PROGRAM MODE 1 March, 2000
4-46
5. Output Test Mode
SP No. Display
5-001 All Indicators On
5-020 Xenon Lamp
5-021-1 Move Scanner - Scan
5-021-2 Move Scanner - Return
5-021-3 Move Scanner to HP
5-040 Master Feed Clutch
5-041 Master Vacuum Fan
5-042-1 Cutter Motor Forward
5-042-2 Cutter Motor Reverse
5-042-3 Move Cutter to HP
5-043-1 Platen Release Motor
5-043-2 Apply Platen Pressure
5-043-3 Release Platen Pressure
5-044 Master Duct Entrance Sol
5-060-1 Pressure Plate to Limit
5-060-2 Press Plate to Eject Pos
5-060-3 Pressure Plate to HP
5-061-1 M Eject Motor Forward
5-061-2 M Eject Motor Reverse
5-080-1 Paper Table Motor Up
5-080-2 Paper Table Motor Down
5-081-1 Paper Pressure Motor Up
5-081-2 Paper Press Motor Down
5-082-1 Sep. Pressure Motor Up
5-082-2 Sep. Pressure Motor Down
5-083-1 Paper Feed Motor Slowest
5-083-2 Paper Feed Motor 30 rpm
5-083-3 Paper Feed Motor 1st
5-083-4 Paper Feed Motor 2nd
5-083-5
Paper Feed Motor 3rd
5-083-6
Paper Feed Motor 4th
5-083-7
Paper Feed Motor 5th
5-083-8
Paper Feed Motor Revs. Slowest (Revs. = reverse rotation)
5-083-9
Paper Feed Motor Revs. 30 rpm
5-083-10
Paper Feed Motor Revs. 1st
5-083-11
Paper Feed Motor Revs. 2nd
5-083-12
Paper Feed Motor Revs. 3rd
5-083-13
Paper Feed Motor Revs. 4th
5-083-14
Paper Feed Motor Revs. 5th
5-084-1
Regist Motor Slowest
5-084-2
Regist Motor 30 rpm
5-084-3
Registration Motor 1st
5-084-4
Registration Motor 2nd
