1 March, 2000 SERVICE PROGRAM MODE
4-47
Service
Tables
SP No. Display
5-084-5
Registration Motor 3rd
5-084-6
Registration Motor 4th
5-084-7
Registration Motor 5th
5-084-8
Regist. Motor Revs. Slowest
5-084-9
Regist. Motor Revs. 30 rpm
5-084-10
Regist. Motor Revs. 1st
5-084-11
Regist. Motor Revs. 2nd
5-084-12
Regist. Motor Revs. 3rd
5-084-13
Regist. Motor Revs. 4th
5-084-14
Regist. Motor Revs. 5th
5-100-1
Wing Guide Motor Up
5-100-2
Wing Guide Motor Down
5-101
Air Knife Fan
5-102
Transport Vacuum Fan
5-120-1
Drum Rotation Slowest
5-120-2
Drum Rotation 1st Speed
5-120-3
Drum Rotation 2nd Speed
5-120-4 Drum Rotation 3rd Speed
5-120-5 Drum Rotation 4th Speed
5-120-6 Drum Rotation 5th Speed
5-121 Printing Pressure Sol.
5-123-1 Shift Pressure Cam to A3
5-123-2 Shift Pressure Cam to A4
5-124-1 Drum Idling Roller ON
5-124-2 Idling Roller Return
5-125-1 Drum Home Pos. LED GREEN
5-125-2 Drum Home Pos. LED RED
5-140-1 Clamper Motor - Open
5-140-2 Clamper Motor - Close
5-141-1
Image Shift Motor - •
5-141-2
Image Shift Motor - •
5-142-1
Drum Shift Motor - •
5-142-2
Drum Shift Motor - •
5-400 Print Counter Up
5-401 Master Counter Up
5-402 Thermal Head ON
5-500 DF Feed Motor
5-501 DF Feed Clutch
5-502 DF Pick-up Solenoid
5-520-1 Slider Lift Motor - Up
5-520-2 Slider Lift Motor - Down
5-521-1 Job Separator Motor Fwd.
5-521-2 Job Separator Motor Rev.
5-540-1 Move S-Plate-Extension
5-540-2 Move S-Plate-Retraction
5-540-3 Move E-Plate-Retraction
