SERVICE PROGRAM MODE 1 March, 2000
4-48
SP No. Display
5-540-4 Move E-Plate-Extension
5-580-1 Count-up Key Card
5-580-2 Key Card Motor
5-660-1 Lead Cam Motor Up For L-Unit
5-660-2 Lead Cam Motor Down For L-Unit
5-660-3 Lead Cam Motor Up For U-Unit
5-660-4 Lead Cam Motor Down For U-Unit
5-660-5 Middle Transport Motor
5-660-6 Horiz. Transport Motor
5-660-7 Lower Vert. Transport Motor
5-660-8 Upper Vert. Transport Motor
5-660-9 ShiftNon/SortMotor To Sort
5-660-10 ShiftNon/SortMotor To Non
5-660-11 S-Jogger For L-Unit Forward
5-660-12 S-Jogger For L-Unit Reverse
5-660-13 S-Jogger For U-Unit Forward
5-660-14 S-Jogger For U-Unit Reverse
5-660-15 E-Jogger For L-Unit Forward
5-660-16 E-Jogger For L-Unit Reverse
5-660-17 E-Jogger For U-Unit Forward
5-660-18 E-Jogger For U-Unit Reverse
5-660-19 Stapler Motor : Forwad
5-660-20 Stapler Motor : Reverse
5-660-21 Mid. Transport Fan Motor
5-660-22 Horz. Transport Fan1 Motor
5-660-23 Horz. Transport Fan2 Motor
5-660-24 Vrt Trans. Fan1 Mtr For L Unit
5-660-25 Vrt Trans. Fan2 Mtr For L Unit
5-660-26 Vrt Trans. Fan1 Mtr For U Unit
5-660-27 Vrt Trans. Fan2 Mtr For U Unit
5-660-28 Wing Guide Solenoid
5-660-29 Non Sort Tray Lock Sol.
5-660-30 Paper Exit Pawl For L-Lnit
5-660-31 Paper Exit Pawl For U-Lnit
5-660-32 JS Sorter Free Rum
5-710-1 R-Tray1 Lift Motor : Up
5-710-2 R-Tray1 Lift Motor : Down
5-710-3 R-Tray1 UnLock Sol. (tray 1 right lock solenoid)
5-710-4 Tray1 Separation Pad Sol (tray 1 friction pad solenoid)
5-710-5 Tray1 Connection Sol.
5-711-1 L-Tray1 Lift Motor : Up
5-711-2 L-Tray1 Lift Motor : Down
5-711-3 L-Tray1 UnLock Sol. (tray 1 left lock solenoid)
5-712-1 Move TrayB-Plate-Right (move back plate drive motor-right)
5-712-2 Move TrayB-Plate-Left (move back plate drive motor-left)
