SERVICE PROGRAM MODE 1 March, 2000
4-22
SP No. Display
Function
Default
User
Tools
1-311-1 Tray2 MisFeed Counter A3
0-
1-311-2 Tray2 MisFeed Cnt. A4B5V
0-
1-311-3 Tray2 MisFeed Cnt. Other
0-
1-312-1 Trans.MisFeed Counter A3
0-
1-312-2 Trans.MisFeed Cnt. A4B5V
0-
1-312-3 Trans.MisFeed Cnt. Other
0-
1-313 Jam Counter Tandem
0-
1-314-1 Jam Cnt. RegistFeed A3
0-
1-314-2 Jam Cnt.RegistFeed A4B5V
0-
1-314-3 Jam Cnt.RegistFeed Other
0-
1-315-1 Tray1 Jam Cnt.Ent. A3
0-
1-315-2 Tray1 Jam Cnt.Ent. A4B5V
0-
1-315-3 Tray1 Jam Cnt.Ent. Other
0-
1-316-1 Tray2 Jam Cnt.Ent. A3
0-
1-316-2 Tray2 Jam Cnt.Ent. A4B5V
0-
1-316-3 Tray2 Jam Cnt.Ent. Other
0-
1-317-1 Tray1 Jam Cnt.MidTrns.A3
0-
1-317-2
Tray1JamCnt.MidTrnsA4B5
V
0-
1-317-3 Tray1JamCnt.MidTrnsOther
0-
1-318-1 Tray2 Jam Cnt.MidTrns.A3
0-
1-318-2
Tray2JamCnt.MidTrnsA4B5
V
0-
1-318-3 Tray2JamCnt.MidTrnsOther
paper trays in the paper
bank unit
V: Longedge feed
Tray 1 Misfeed: Jam at the
tray registration rollers
when feeding from tray 1
Tray2 Misfeed: Jam at the
2nd relay rollers
Trans Misfeed: Jam at the
tray registration rollers
when feeding from tray 2
Tandem: Jam in the
tandem tray
Regist Feed: Includes the
following – paper detected
at power-up at the 3rd relay
roller, between the 3rd
relay roller and main body
registration roller, and at
the tray registration roller;
jams at the main body
registration roller, opening
the cover during a job, and
paper wrapping jams
(upper and lower)
Ent: Jams at the 3rd relay
roller
Mid Trns.: Includes the
following – jam between the
3rd relay roller and main
body registration roller, jam
in the vertical transport
section in the paper bank
unit, jams at the tray
registration roller
0-
1-320-1 1Master Print Cnt. 1-20
0-
1-320-2 1Master Print Cnt. 21-40
0-
1-320-3 1Master Print Cnt. 41-50
0-
1-320-4 1Master Print Cnt. 51-80
0-
1-320-5 1Master Print Cnt.81-
Master counters for sorter
mode. For details, see the
sorter service manual.
0-
1-321-1 Master Cnt.on Sort 1-5
0-
1-321-2 Master Cnt.on Sort 6-10
0-
1-321-3 Master Cnt.on Sort 11-20
0-
1-321-4 Master Cnt.on Sort 21-30
0-
1-321-5 Master Cnt.on Sort 31-50
0-
1-321-6 Master Cnt.on Sort 51-
Job counters for sorter
mode. For details, see the
sorter service manual.
0-
