1 March, 2000 SERVICE PROGRAM MODE
4-21
Service
Tables
SP No. Display
Function
Default
User
Tools
1-207-5
Jam% Paper Lower Wrap
0-
1-207-6
Jam% Paper Exit OFF Chk
0-
1-300-1 Jam P0 Standard
0-
1-300-2 Jam P0 Thick
0-
1-300-3 Jam P0 Others
Feed-in jams and
registration roller jams for
various paper sizes and
paper types
‘-L’: Lengthwise
0-
1-301-1 Jam P1 Standard
0-
1-301-2 Jam P1 Thick
0-
1-301-3 Jam P1 Others
Registration roller jams
(when the paper feed
timing sensor stays on) for
various paper sizes and
paper types
‘-L’: Lengthwise
0-
1-302-1 Jam P2 A3/B4 Standard
0-
1-302-2 Jam P2 A3/B4 Thick
0-
1-302-3 Jam P2 A3/B4 Others
0-
1-303-1 P Count A3/B4 Standard
0-
1-303-2 P Count A3/B4 Thick
0-
1-303-3 P Count A3/B4 Others
Upper wrap, lower wrap,
and feed-out jams for
various paper sizes and
paper types
‘-L’: Lengthwise
0-
1-304-1 M Set Error Low Temp
0-
1-304-2 M Set Error Normal Temp
0-
1-304-3 M Set Error High Temp
0-
1-305-1 M Clamp Error Low Temp
0-
1-305-2 M Clamp Error Nor. Temp
0-
1-305-3 M Clamp Error High Temp
0-
1-306-1 M Cut Error Low Temp
0-
1-306-2 M Cut Error Normal Temp
0-
1-306-3 M Cut Error High Temp
Master error counters for
different temperature
conditions (temperature
detected by the thermistor
in the drum)
0-
1-307-1 M Eject ON Jam Low Temp
0-
1-307-2 M Eject ON Jam Nor Temp
0-
1-307-3 M Eject ON Jam High Temp
0-
1-308-1 Press Plate Error Low
0-
1-308-2 Press Plate Error Normal
0-
1-308-3 Press Plate Error High
0-
1-309-1
M Eject OFF Jam Low
Temp
0-
1-309-2 M Eject OFF Jam Nor Temp
0-
1-309-3 M Eject OFF Jam High Tem
0-
1-310-1 Tray1 MisFeed Counter A3
0-
1-310-2 Tray1 MisFeed Cnt. A4B5V
0-
1-310-3 Tray1 MisFeed Cnt. Other
Feed-in jams and tray
registration roller jams for
various paper sizes for the
0-
