20 February, 2001 SPECIFICATIONS
SPEC-9
Spec.
TWO-TRAY PAPER TRAY UNIT
Paper Size:
A5 to A3
5
1/2
" x 8
1/2
" SEF to 11" x 17"
Paper Weight: 60 – 105 g/m
2
, 16 – 28 lb.
Tray Capacity: 500 sheets (80 g/m
2
, 20 lb.) x 2 trays
Paper Feed System: Feed roller and friction pad
Paper Height Detection: 4 steps (100%, 70%, 30%, Near end)
Power Source: 24 Vdc, 5 Vdc (from the copier/printer)
120 Vac:
120 V version, from the copier/printer when the
optional tray heater is installed
220 – 240 Vac:
230 V version, from the copier/printer when the
optional tray heater is installed
Power Consumption: Max: 30 W (Copying/printing)
23 W (Optional Tray Heater On)
Average: 17 W (Copying/printing)
15 W (Optional Tray Heater On)
Weight: 25 kg (55 lb.)
Size (W x D x H): 550 mm x 520 mm x 271 mm
16MB IMB (Copier Memory Unit)*
Memory:
16MB (with slot for 32MB expansion DIMM)
*This component is included as standard on all models other than B039 machines
sold outside of North America.
