USING SERVICE PROGRAM MODES 20 February, 2001
5-36
5.1.4 OUTPUT CHECK (SP5-804)
CAUTION: To prevent mechanical or electrical damage, do not keep an electrical
component on for a long time.
1. Access SP mode 5-804.
2. Select the SP number that corresponds to the component you wish to check
(see the table below), then press OK or !.
3. Press “1”, then press OK or the ! key to check that component.
4. To interrupt the test, re-enter SP mode 5-804 and enter a value of “0”.
Output Check Table
NOTE: Pull out the tray before performing output checks 28, 29, and 31.
Number Description
0 Not used
1 Main motor (Forward)
2 Main motor (Reverse) Do not use
3 Quenching lamp
4 – 6 Not used
7 Toner supply motor (Forward)
8 Toner supply motor (Reverse)
Do not use
9 Exhaust fan (High Speed)
10 Exhaust fan (Low Speed)
11 Registration clutch
12 By-pass feed clutch
13 Upper paper feed clutch
14 Lower paper feed clutch
15 – 18 Not used
19 Lower paper lift motor (Up)
(Optional paper tray unit)
20
Lower paper lift motor (Down)
(Optional paper tray unit)
21 Relay clutch
22 Not used
23 Relay clutch (Optional paper tray
unit)
24, 25 Not used
26
Upper paper feed clutch
(Optional paper tray unit)
27 Lower paper feed clutch
(Optional paper tray unit)
28
Paper feed motor (Optional paper
tray unit)
Number Description
29
Upper paper lift motor (Up)
(Optional paper tray unit)
30 Not used
31 Upper paper lift motor (Down)
(Optional paper tray unit)
32 – 39 Not used
40 Duplex inverter motor (Reverse)
41 Duplex inverter motor (Forward)
42 Duplex transport motor (Forward)
43 Duplex inverter gate solenoid
44 Duplex inverter motor (Hold)
45 Duplex transport motor (Hold)
46 – 50 Not used
51 Polygonal mirror motor
52 Polygonal mirror motor and laser
diode
Do not use
53
Laser diode Do not use
54 – 89 Not used
90 DF transport motor (Optional ADF)
91 DF feed motor (Optional ADF)
92 DF feed clutch (Optional ADF)
93
DF pick-up solenoid (Optional
ADF)
94 Stamp solenoid (Optional ADF)
95 DF junction gate solenoid
(Optional ADF)
96 – 99 Not used
Output Check
Code: 0 Data: 0
B039M007.WMF
