PM TABLES 20 February, 2001
2-2
EM 60k 120k AN NOTE
Paper feed guides C C Clean with water or alcohol.
Paper-dust Mylar C C Clean with water or alcohol.
FUSING UNIT
Hot roller R
Pressure roller R
Hot roller bushings I
Pressure-roller
bushing
R
Hot roller stripper
pawls
RC
Dry cloth
Thermistor C C Dry cloth
80k AN NOTE
ADF, ARDF
Feed belt R C Clean with water or alcohol.
Separation roller R C Clean with water or alcohol.
Pick-up roller R C Clean with water or alcohol.
Stamp R Replace when necessary.
White plate C Clean with water or alcohol.
DF exposure glass C Clean with water or alcohol.
Platen cover C Clean with water or alcohol.
60k 120k AN NOTE
PAPER TRAY UNIT (ONE-TRAY AND TWO-TRAY MODELS)
Paper feed rollers R C Dry or damp cloth
Bottom-plate pads C C Dry cloth
Paper-feed guides C C Clean with water or alcohol.
Friction pads R C Dry or damp cloth
PAPER TRAY UNIT (TWO-TRAY MODEL ONLY)
Relay clutch I
Feed clutches I
Relay roller C C Dry cloth
