IP-Fax Troubleshooting
D649 48 SM
3.3.2 IP-FAX RECEPTION
Cannot receive via IP Address/Host Name.
Check Point Action
1 LAN cable connected? Check the LAN cable connection.
2 Firewall/NA T is installed?
Cannot breach the firewall. Send by using
another method (Fax, Internet Fax)
3 IP address of local fax registered? Register the IP address.
4
Port number specified at remote sender
fax (if required)?
Request the sender to specify the port
number.
5
Specified port number correct (if
required)?
Request the sender to check the port
number.
6
DNS server registered when host name
specified on sender side?
Contact the network administrator.
 The sender machine displays this
error code if the sender fax is a
Ricoh model.
7 Network bandwidth too narrow?
Request the system administrator to
increase the bandwidth.
Lower the start modem reception baud
rate on the receiving side.
IPFAX SW06
8 Remote fax cancelled transmission?
Check whether the remote fax cancelled
the transmission.

Ricoh MP C305SPF Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
ADF Capacity	50 sheets
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan, Fax
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Print Speed	30 ppm
Paper Capacity	350 sheets
Paper Size	A4, A5, A6, B5
Fax Transmission Speed	Approximately 3 seconds per page
Operating System Compatibility	Windows, Mac, Linux
