Ricoh MP C305SPF User Manual

Process Control Error Conditions
SM 6-79 D117/D118
Troubleshooti
ng
Vsg Adjustment Result
SP3-323-001 to -010 (Vsg Adjustment Result)
No. Result Description Possible Causes/Action
1 O.K
Vsg adjustment
is correctly done.
-
2
ID sensor
adjustment
error
Vsg cannot be
adjusted within
4.0 ±0.5V.
 Dirty ID sensor (toner, dust, or foreign
material)
 Dirty transfer belt
 Scratched image transfer belt
 Defective ID sensor
 Poor connection
 Defective BICU
1. Clean the ID sensor.
2. Check the belt cleaning. Clean or replace the
transfer belt.
3. Replace the image transfer belt.
4. Replace the ID sensor.
5. Check the connection.
6. Replace the BICU board.
3
ID sensor
output error
ID sensor output
is more than
"Voffset
Threshold"
(SP3-324-004)
 Defective ID sensor
 Poor connection
 Defective BICU
1. Replace the ID sensor.
2. Check the connection.
3. Replace the BICU board.
9
Vsg
Adjustment
error
Vsg adjustment
has not been
completed.
 Other cases
Retry SP3-321-010.

Ricoh MP C305SPF Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
ADF Capacity	50 sheets
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan, Fax
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Print Speed	30 ppm
Paper Capacity	350 sheets
Paper Size	A4, A5, A6, B5
Fax Transmission Speed	Approximately 3 seconds per page
Operating System Compatibility	Windows, Mac, Linux
