Ricoh MP C305SPF User Manual

Troubleshooting Guide
SM 6-89 D117/D118
Troubleshooti
ng
6.3.4 ALL-BLACK PRINT
Symptom Possible cause Necessary actions
All the paper is black.
Incorrectly installed PCDU Install the PCDU correctly.
Defective PCDU Replace the PCDU.
Defective HVPS Replace HVPS.
Defective laser unit Replace the laser unit.
Defective BICU Replace the BICU.
Defective main board Replace the main board.
6.3.5 MISSING CMY COLOR
Symptom Possible cause Necessary actions
C, M, or Y is missing.
Defective PCDU Replace the PCDU.
Loose connection between
printer cartridge and BICU
Replace the drum
positioning cover.
Image transfer belt not
contacting PCDU
Check the belt tension unit.
Defective the drum motor:
CMY
Replace the drum motor:
C M Y.
Defective BICU Replace the BICU.

Ricoh MP C305SPF Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
ADF Capacity	50 sheets
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan, Fax
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Print Speed	30 ppm
Paper Capacity	350 sheets
Paper Size	A4, A5, A6, B5
Fax Transmission Speed	Approximately 3 seconds per page
Operating System Compatibility	Windows, Mac, Linux
