Maintenance
Color Mode [Color]
[K]: Black in B&W mode
[Y], [M], or [C]: Yellow, Magenta, or Cyan in Full Color mode
[YMC]: Only for Yellow, Magenta, and Cyan
[FC]: Full Color mode
[FC, K], [FC, Y], [FC, M], or [FC, C]: Black, Yellow, Magenta, or Cyan in full color mode
Print Mode
S: Simplex
D: Duplex
Process Speed
L: Low speed (89 mm/s)
M: Middle speed (178 mm/s)
Others
The following symbols are used in the SP mode tables.
FA: Factory setting
(Data may be adjusted from the default setting at the factory. Refer to the factory setting sheets
enclosed. You can find it under the jammed paper removal decal.)
DFU: Design/Factory Use only
Do not touch these SP modes in the field.
A sharp (#) to the right hand side of the mode number column means that the main switch must be
turned off and on to effect the setting change.
An asterisk (*) to the right hand side of the mode number column means that this mode is stored
in the NVRAM and EEPROM. If you do a RAM clear, this SP mode will be reset to the default
value. "ENG" and "CTL" show which NVRAM contains the data.
 ENG: EEPROM on the BICU board
 CTL: NVRAM on the controller board
The settings of each SP mode are explained in the right-hand column of the SP table in the
following way.
[Adjustable range / Default setting / Step] Alphanumeric
 If "Alphanumeric" is written to the right of the bracket as shown above, the setting of the
SP mode shows on the screen using alphanumeric characters instead of only numbers.
However, the settings in the bracket in the SP mode table are explained by using only the
numbers.
SSP: This denotes a "Special Service Program" mode setting.
