Service Program Mode
D117/D118 5-4 SM
Service Mode Lock/Unlock
At locations where the machine contains sensitive data, the customer engineer cannot operate
the machine until the Administrator turns the service mode lock off. This function makes sure that
work on the machine is always done with the permission of the Administrator.
1. If you cannot go into the SP mode, ask the Administrator to log in with the User Tool and then
set "Service Mode Lock" to OFF after he or she logs in:
User Tools
System Settings Administrator Tools Service Mode Lock OFF
 This unlocks the machine and lets you get access to all the SP codes.
 The CE can service the machine and turn the machine off and on. It is not necessary to
ask the Administrator to log in again each time the machine is turned on.
2. Go into the SP mode and set SP5169 to "1" if you must use the printer bit switches.
3. After machine servicing is completed:
 Change SP5169 from "1" to "0".
 Turn the machine off and on. Tell the administrator that you have completed servicing the
machine.
 The Administrator will then set the "Service Mode Lock" to ON.
5.1.4 REMARKS
Display on the Control Panel Screen
The maximum number of characters which can show on the control panel screen is limited to 30
characters. For this reason, some of the SP modes shown on the screen need to be abbreviated.
The following are abbreviations used for the SP modes for which the full description is over 20
characters.
Paper Weight
Plain Paper 1: 60-74 g/m
2
, 16-20lb.
Plain Paper 2: 75-81 g/m
2,
20-22lb.
Middle Thick: 82-105 g/m
2
, 22-28lb.
Thick Paper 1: 106-130 g/m
2
, 28.3-34.6lb.
Thick Paper 2: 131-163 g/m
2
, 35-43lb.
Thick Paper 3: 164-220 g/m
2,
44-58lb.
Paper Type
N: Normal paper
MTH: Middle thick paper
TH: Thick paper
Paper Feed Station
P: Paper tray
B: By-pass table
