SC Tables
D117/D118 6-52 SM
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
835
CTL
B
Self-diagnostic error: Standard SDRAM DIMM
[XXXX]: Detailed error code
[1102]
Loopback connector is connected but check results in an error.
 IEEE1284 connector error
 Centronic loopback connector defective
1. Replace the controller board.
[110C]
Loopback connector is connected but check results in an error.
 ASIC device error
 IEEE1284 connector error
 Centronic loopback connector defective
1. Replace the controller board.
[1120]
Centronic loopback connector is not connected for detailed
self-diagnostic test.
 Centronic loopback connector not connected correctly
 Centronic loopback connector defective
 ASIC device defective
1. Replace the controller board.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
838
CTL
D
Self-diagnostic Error: Clock Generator
[XXXX]: Detailed error code
[2701]
A verify error occurred when setting data was read from the clock
generator via the I2C bus.
 Defective clock generator
 Defective I2C bus
 Defective I2C port on the CPU
1. Replace the controller board.

Ricoh MP C305SPF Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
ADF Capacity	50 sheets
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan, Fax
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Print Speed	30 ppm
Paper Capacity	350 sheets
Paper Size	A4, A5, A6, B5
Fax Transmission Speed	Approximately 3 seconds per page
Operating System Compatibility	Windows, Mac, Linux
