Electrical Component Defects
D117/D118 6-106 SM
No.
Sensor Name/
Sensor Board
Name
Active
CN No./
Pin No.
Condition Symptom
SW5
Paper tray set
sensor
L CN543/15
Open
 Paper tray cannot
be detected.
Shorted
 Paper tray is
detected when
the paper tray is
not set.
SW6
Waste toner bottle
set sensor
L CN535/1
Open
 Waste toner
bottle cannot be
detected.
Shorted
 Waste toner
bottle is detected
when the waste
toner bottle is not
set.

Ricoh MP C305SPF Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
ADF Capacity	50 sheets
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan, Fax
Scanner Type	Flatbed, ADF
Fax Speed	33.6 Kbps
Print Speed	30 ppm
Paper Capacity	350 sheets
Paper Size	A4, A5, A6, B5
Fax Transmission Speed	Approximately 3 seconds per page
Operating System Compatibility	Windows, Mac, Linux
