Parts List
Service Parts List
No. Items Image Reference
1
Optical Engine (with
Focus Lever)
page 63
2 Engine Unit page 65
3 Filter Wheel page 65
4 Combiner Unit page 65
5 Sheet for Heat Sink page 53
Parts List
33
