Ricoh PJ LX3000ST Field Service Manual

Item Name on board Key feature Figure
G
SPK
(to Speaker)
Compose of Red/Black
Wire(2 pin)
H
LD IF
(To LD Driver Board)
FFC cable
I DMD FAN
Compose of Red/Blue/
Black Wire (3 pin)
J Sys FAN
Compose of Red/Yellow/
Black Wire(3 pin)
IO Board, Audio Board
The IO Board and Audio Board are attached on Main Board.
[A]: Main Board
[B]: Audio Board
[C]: IO Board
