Adjustment
Wheel Index Adjustment
After replacing the main board, combiner unit, filter wheel, or engine unit, the Wheel Index Adjustment
should be done.
Environment
• Test pattern: Full Color Pattern [A], 64 gray RGBW [B]
1. Connect the projector to PC with HDMI or VGA cable, and then, turn ON the main power.
2. Enter the Service mode. (page 73)
4. Adjustment
76
To Next Page
