009: [Erase Margin: Leading Edge]
Adjust the mask width at the leading edge of the image.
By increasing the mask width, you can increase the paper margin at the leading edge of the paper.
Press [+] to increase the mask width and [−] to reduce it.
Top
Bottom
Trailing edgeLeading edge
CEZ020
Paper feed direction
Setting Items Max. Value Min. Value Step Unit
[Erase Margin: Leading Edge] 6.0 -3.0 0.1 mm
010: [Erase Margin: Trailing Edge]
Adjust the mask width at the trailing edge of the image.
By increasing the mask width, you can increase the paper margin at the trailing edge of the paper.
Press [+] to increase the mask width and [−] to reduce it.
CEZ021
Top
Bottom
Trailing edgeLeading edge
Paper feed direction
Setting Items Max. Value Min. Value Step Unit
[Erase Margin: Trailing Edge] 6.0 -3.0 0.1 mm
4. Details of Menu Items in Advanced Settings
118
