0203: [Maximum Image Density]
Specify the adhesion of toner to the drum surface and intermediate transfer belt when image density
adjustment is executed.
If color reproduction is affected by the toner's color intensity difference, adjust the toner adhesion.
After specifying this setting, execute [Adjust Image Density/DEMS].
Press [+] or [−] to adjust the toner adhesion.
Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
[Black] 0 5 -5 1 None
[Cyan]
[Magenta]
[Yellow]
• Increasing the toner adhesion might reduce fusibility, causing toner splatter or distorted text and
thin lines.
0204: [Line Width]
Adjust the intensity of the laser for transferring image data to the drum.
If you increase the laser intensity, the line width is increased. By adjusting the laser intensity, you can
adjust the line width.
After specifying this setting, execute [Adjust Image Density/DEMS].
Press [+] or [−] to adjust the laser intensity.
Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
[Black] 0 5 -5 1 None
[Cyan]
[Magenta]
[Yellow]
2. Details of Menu Items in Adjustment Settings for Skilled Operators
34

Ricoh Pro C5200s Specifications

General

Print Technology	Laser
Max Paper Size	330.2 x 487.7 mm
Monthly Duty Cycle	300, 000 pages
Print Speed	65 ppm
Resolution	1200 x 4800 dpi
Paper Input Capacity	8, 250 sheets
Paper Weight	52 to 360 gsm
Duplex Printing	Standard
Network Connectivity	Ethernet 10Base-T/100Base-TX/1000Base-T
Supported Media Sizes	A3, A4, A5, B4, B5
Supported Media Types	Plain, Recycled, Coated, Envelope
Warm-up Time	Less than 5 minutes
