Leading Edge Guide Motor
1.
Corner stapling unit (
page 21
)
2.
Stapler bracket [A] (
×3,
×1)
3.
Leading edge guide motor [A] (
×2,
×1)
Leading Edge Guide HP Sensor
1.
Corner stapling unit (
page 21
)
1. Replacement and Adjustment
28
