5.
Bottom paper exit sensor [A] (
×1,
×1)
Booklet Paper Sensor (Upper)
1.
Booklet unit (
page 60
)
2.
Bracket [A] (
×1,
×1,
×2)
1. Replacement and Adjustment
80
81
83
