2. Horizontal transport motor [A] ( ×2, ×1, ×1)
Tray Lift Motor
1. Rear upper cover (page 7)
2. Upper cover (page 7)
3. Bracket [A] ( ×3, ×2)
1. Replacement and Adjustment
42
