2.
Folding Transport Motor [A] (
×2,
×1,
×1)
Booklet Stapler Motor Unit
1.
Booklet unit (
page 60
)
2.
Release the clamps and remove the screws securing the booklet stapler motor unit and
booklet unit. (
×2,
×3)
