4.
Proof tray exit sensor [A] (
×1)
Positioning Roller Motor / Feed Out Guide HP Sensor
1.
Front inner cover (
page 9
)
2.
Positioning roller motor bracket [A] (
×3,
×2,
×2)
3.
Positioning roller motor [A] (
×2,
×1)
Main Unit
53
54
56
