Ricoh SR3170 - Shift Tray Paper Sensor

3. Turn back the stapler bracket, and remove the trailing edge pressure plate HP sensor
bracket [A] ( ×1)
4. Trailing edge pressure plate HP sensor [A] ( ×1)
Shift Tray Paper Sensor
1. Corner stapling unit (page 21)
Corner Stapling Unit
31
