3.
Middle transport motor [A] (
×2)
Pre-stack Transport Motor
1.
Rear upper cover (
page 7
)
2.
Pre-stack transport motor [A] (
×2,
×1,
×1)
Entrance Transport Motor
1.
Rear upper cover (
page 7
)
1. Replacement and Adjustment
