Ricoh SR3170 - Shift Tray Lower Limit Sensors; Booklet Paper Full Sensor 1, Booklet Paper Full Sensor 2 (D688 Only)

5. Paper transport sensor [B]
Shift Tray Lower Limit Sensors
1. Rear upper cover (page 7)
2. Rear lower cover (page 7)
3. Shift tray lower limit sensors [A] ( ×1 for each sensor)
Booklet Paper Full Sensor 1, Booklet Paper Full Sensor 2 (D688 Only)
1. Booklet unit (page 60)
