1.Detailed Descriptions
21
No.
Part
4
Booklet Exit Sensor (S6)
5
Fold Plate Cam HP Sensor (S9)
6
Fold Transport Motor (STM9)
7
Press Fold Motor (STM10)
Punch Unit (Option)
No.
Part
1
Punch Unit Movement Motor (STM13)
2
Punch Unit HP Sensor (S40)
3
Punch Registration HP Sensor (S41)
4
Punch Registration Motor (STM14)
5
Punch Registration Sensor (S43)
6
Punchout Hopper Full Sensor (S42)
7
Punch HP Sensor (S38)
8
Punch Drive Motor (DCM13)
9
Punch Motor Rotation Sensor (S39)
10
Punch Unit Controller Board (PCB2)
